| H-Series" HELICAL / BEVEL HELICAL GEARBOX |
 |
Case hardened and Profile ground Steel Gears with inclined tooth to transmit the torque between parallel / Right Angle shafts with minimum noise. |
Range - Power range upto 5500 Kw |
Sizes - From 125mm to 850mm center distance |
| Type - Helical / Bevel Helical |
| Applications - 50Kw Agitators, Conveyors, Crushers, Cranes, Larger Ball Mills, Mixers, Aerators, Fin Cooler Drives, Kneaders, Thickeners |
| Industries - Sugar, Cement, Paper, Solvent Extraction, Rubber, Steel Industry, Power Plants, Mines and Minerals, Chemical |
|
|
| VERTICAL COAL PULVERIZING MILL GEARBOX |
 |
Bevel helical gear units capable of taking large vertical downward thrust load. Cast Iron Case designed to absorb excess vibration during running of mill. |
Range - Power range upto 400Kw |
Sizes - From 760mm to 1000mm center distance |
| Type - 8.5 ES / 8.5 EX / 10P - (2/3 Stage) |
| Applications - Vertical Coal Pulverizing |
| Industries - Cement, Paper, Steel Industry & Power Plants |
|
|
| BEVEL HELICAL COOLING TOWER GEARBOX |
 |
Case hardened and Profile ground Steel Gears with inclined tooth to transmit the torque between parallel shafts with minimum noise for input speed upto 10000 RPM |
Range - Power range upto 600 Kw Reduction Ratio upto 15.4/1 |
Sizes - From 140mm to 600mm center distance |
| Type - 'B' series and 'ABM' series |
| Applications - Cooling Tower and Heat Exchanger Application |
| Industries - Sugar, Cement, Paper, Power Plants,Solvent Extraction and Steel Industry |
|
|
| OPEN GEARING |
 |
Premium Helical Gears are manufactured out of high quality alloy case hardened steel. The gears are case carborised using the latest gas carborising processes. The gears are profile ground to finish upto DIN 2 class using the latest form grinders in the industry. |
Range - Customer Specific |
Sizes - Up to DIN Class 2 |
| Type - Case Carborised & Profile Ground Helical Gears 58 ± RC |
| Applications - Marine, Windmill, Turbine Gears |
|
|
| GHE Series" EXTRUDER GEARBOX |
 |
The gear units are quite capable to transmit the high torque required for pressurising and plasticising moulding materials and also to absorb the high axial thrust load through built-in spherical roller thrust bearing. The axial bearing housing is standardised to accommodate suitable thrust bearings and corresponding output shafts with key are splined. |
Range - Power range upto 250 Kw |
Sizes - From 112mm to 355mm center distance |
| Type - Single screw extruder |
| Applications - Plastic Extrusion & PVC Extrusion |
| Industries - Plastic Industry |
|
|
|
